Precision Cold Heading at Its Best.
| Model | Machinable Outer Diameter (mm) | Max. Machinable Length (mm) | Max. Thread Rolling Length (mm) | Movable Die Plate (mm) | Fixed Die Plate (mm) | Production Capacity (PCS/min) | Main Motor Power (kW) | Net Weight (kg) | Overall Dimensions (cm) |
| BTR432 | 2-4 | 20 | 20 | 100*25*45 | 85*25*45 | 240-270 | 2.2 | 1100 | 180*102*164 |
| BTRV432 | 2-4 | 42 | 38 | 100*25*45 | 85*25*45 | 240-270 | 2.2 | 1100 | 180*102*164 |
| BTR550 | 3-5 | 50(75) | 50 | 105*25*50 | 90*25*50 | 210-250 | 4 | 1550 | 200*110*185 |
| BTR575 | 3-5 | 75(100) | 75 | 105*25*75 | 90*25*75 | 150-180 | 4 | 1800 | 200*110*185 |
| BTR650 | 3-6 | 50(75) | 50 | 105*25*50 | 90*25*50 | 200-225 | 5.5 | 1900 | 214*118*183 |
| BTR675 | 3-6 | 75(100) | 75 | 105*25*75 | 90*25*75 | 150-180 | 5.5 | 2100 | 214*118*183 |
Note:
1. The Company reserves the right to modify the above specifications without prior notice.
2. The applicable production speed depends on the product’s shape, dimensions, and material.
3. Please contact the Company for confirmation if you need to produce stainless steel or special high-strength products.
